Siemens Motor Circuit Breaker (3MV8100-1ML00)
₦257,400.00
Siemens 3MV8100-1ML00 motor circuit breaker with adjustable current range of 6–10A for precise motor protection.
Integrated 1NO+1NC auxiliary contacts enable efficient control circuit signaling and monitoring.
Compact and robust unit with screw terminals ensures secure installation in industrial control panels.
The Siemens 3MV8100-1ML00 motor circuit breaker is designed to protect low-voltage motors against overload, short circuit, and phase failure. Its adjustable current range of 6 to 10A allows accurate matching to motor full-load current, ensuring reliable protection and minimizing the risk of downtime or equipment damage.
This model includes built-in auxiliary contacts (1NO + 1NC), providing flexibility for integration into control and automation systems for status indication and interlocking functions. The screw terminal connection design ensures stable electrical contact, while its compact form factor supports easy installation in standard distribution and control panels.
Typical Applications
• Motor protection in industrial control panels
• Pump and fan control systems
• Conveyor and material handling equipment
• HVAC and ventilation systems
• Manufacturing and automation processes
| manufacturer | siemens |
|---|---|
| model | 3MV8100-1ML00 |
| weight | Approx. 0.35 kg |
| Rated voltage | 690 V AC |
| Rated current | 6–10 A (adjustable) |
| motor power/Rated power | Up to 4 kW (at 400 V AC) |
| control voltage | Not required (manual operation) |
| number of poles | 3 pole |
| Auxilary contacts | 1NO + 1NC |
| Mounting type | DIN rail / Panel mounting |
| frequency | 50/60 Hz |
| protection type | Ip 20 |
| operating temperature | -20°C to +60°C |
